Flanged Swing Check Valve Drawings

on . Posted in Valve Drawings

Number of Drawings: 19
Flanged Swing Check Valve Drawings
$4.99

This Isometric Package contains blocks for flanged swing check valves in different ANSI Classes.  This drawing package contains 19 blocks!

pdfSwing Check Valve Drawing Example28.5 KB

PD CV Swing Flg 150ANSI 150 Gate Valve Drawing



All the blocks have been created on 'Layer 0' and can be either copied into your working drawing or can be copied into your pallettes. The drawing is saved as a .dwg file and includes drawings for:

  • Sizes: 2", 3", 4" 6" to 20" and 24"
  • Wedge Gate Valves, ANSI Class 150
  • Wedge Gate Valves, ANSI Class 300
  • Wedge Gate Valves, ANSI Class 600
  • Wedge Gate Valves, ANSI Class 900
  • Wedge Gate Valves, ANSI Class 1500
  • Wedge Gate Valves, ANSI Class 2500

Drawing file will work  in the following formats:

  • AutoCAD 2013/ LT2013
  • AutoCAD 2010/ LT2010
  • AutoCAD 2004/ LT2004

Have questions about when to use these valves in your design?  Check out our articles or datasheets:
